3ZONES SECURITY ALARM CONTROL PANEL DSM-300
Short Description:
- Min.Order Quantity: 100 Piece/Pieces
- Supply Ability: 10000 Piece/Pieces per Month
- Port: Shenzhen
- Payment Terms: L/C,D/A,D/P,T/T
描述
| Enclosure Design | |
| Color: | Frost White |
| Indicators: | 3 zone LEDS, 2 status LEDs |
| Dimensions (HxWxD): | |
| Environmental Considerations | |
| Relative Humidity: | 0% to 85% noncondensing |
| Temperature (Operating): | 20°C to +50°C |
| Outputs | |
| Alarm Relay: | Form “C”,contacts rated at 3 A @ 28 VDC or 120 VAC |
| Solid-State: | Two DC current sinks; 250 mA maximum per output at 0.1 VDC saturation. |
| Power Requirements | |
| Current Draw: | 30 mA standby, 70 mA alarm |
| Voltage (Input): | 10.2 VDC to 15 VDC |
| Zone Characteristics | |
| EOL Resistors: | 10 kΩ |
| Response Time: | 500 ms |
Control Panels,Alarm System
The mini panel has three alarm input zones,one alarm relay output,two solid-state outputs,key switch input,instant input and supports three user PIN codes including the master code and one door unlock PIN code.
3 zones and a separate key-switch input
3 user codes and an unlock door code
Quick Arm function
Built-in piezo buzzer
Built-in tamper switch
Keys back-lit by LEDs
